6-TIME BEST GENERATOR AWARD WINNER
Gentrax GT3500 Inverter Generator
Lighter, Quieter, Safer.
|
|
|
|
|
| Catalogue | Blade | Slim | General | General |
| Life Cycles | 3000+ | 3000+ | 3000+ | 3000+ |
| Nominal Voltage(v) | 12.8V | 12.8V | 12.8V | 12.8V |
| Usable Capacity(Ah) | 100Ah | 100Ah | 100Ah | 200Ah |
| Nominal Capacity(Ah) | 100Ah | 100Ah | 100Ah | 200Ah |
| Rated Energy(wh) | 1280Wh | 1280Wh | 1280Wh | 2650Wh |
| Charging Voltage(V) | 14.2 - 14.6V | 14.2 - 14.6V | 14.2 - 14.6V | 14.2 - 14.6V |
| Max. Continuous Discharge Current(A) | 100A | 100A | 100A | 100A |
| Max. Discharge Current 5 sec(A) | 200A | 200A | 200A | 200A |
| Charge Temperature | 0-50℃ | 0-50℃ | 0-50℃ | 0-50℃ |
| Discharge Temperature | 20-60℃ | 20-60℃ | 20-60℃ | 20-60℃ |
| Storage Temperature | -10℃ ～50℃ | -10℃ ～50℃ | -10℃ ～50℃ | -10℃ ～50℃ |
| Approx Life Cycles | 2000+ | 2000+ | 2000+ | 2000+ |
| BMS(A) | 100A | 100A | 100A | 100A |
| Warranty | 2 Years | 2 Years | 2 Years | 2 Years |
| Certify | UN38.3 | UN38.3 | UN38.3 | UN38.3 |
| Brand | Gentrax | Gentrax | Gentrax | Gentrax |
| Gain Weight | 15kg | 9.5kg | 9.5kg | 19kg |
| Net Weight | 16kg | 10.4kg | 10.4kg | 20kg |
| Product Size | 630*240*60 | 395*110*286 | 306*169*215 | 345*190*245 |
| Package Size | 704*313*140 | 458*172*346 | 360*230*271 | 422*242*305 |
| 20GP | 560-600 | 760-840 | 900-1050 | 600 |
| 40HC | 1120-1200 | 1520-1862 | 1785-2100 | 1140 |
| Case Material | metal-iron | ABS | ABS | ABS |
| Cell Grouping（cell Series ＆ Parallels) | 4S2P | 4S2P | 4S2P | 4S2P |
| Factory-Battery Parallel Connection: | 4p(max) | 4p(max) | 4p(max) | 4p(max) |
| Factory- Battery Series Connection: | N | N | N | N |
| C rating (C) | 1C | 1C | 1C | 0.5C |
| Protection Class（IP) | / | IP65 | IP65 | IP65 |
| Charge Method | CC/CV | CC/CV | CC/CV | CC/CV |
| Charging Voltage(V) | 14.2-14.6V | 14.2-14.6V | 14.2-14.6V | 14.2-14.6V |
| Discharge Cut-off voltage | 10V | 10V | 10V | 10V |
| Standard Charging Current(A) | 50A | 50A | 50A | 50A |
| Max. Charging Current(A) | 100A | 100A | 100A | 100A |
| Standard Discharge Current(A) | 100A | 100A | 100A | 100A |
| Bolt Type | N | M8*2 | M8*2 | M8*2 |
| Overcharge Protection(V) | 14.6V | / | 14.6V | - |
| Overcharge Recovery(V) | 14.4V | / | 14.4V | / |
| Overdischarge Protection(V) | 10V | / | 10V | / |
| Overdischarge Recovery(V) | 11V | / | 11V | / |
| Absorption Voltage(V) | 14.2-14.6V | / | 14V | / |
| Float Charging | 14.2-14.6V | / | 15V | / |
| Bolt Material | N | Iron nickel-plated | Iron nickel-plated | Iron nickel-plated |
| Bolt Terminal Size (Length) | N | Hexagon x 14mm | Hexagon x 14mm | Hexagon x 14mm |
| Bolt Terminal Perimeter | N | 25.12mm | 25.12mm | 25.12mm |
Choose an appliance category:
Power Your Adventures
10% OFF our best-selling 3.5kW generator and 100Ah LiFePO4 Battery
Gentrax Essentials
Find the parts and accessories for your model of generator
Why Gentrax?
Gentrax inverter generators have been voted the best in the market for the 6th time in 2024 via Product Review. A real stand out among other generators, our units offer better fuel efficiency, a quiet runtime, and reliable performance all at affordable prices. These are your most reliable mates whether on adventures or during a sudden power outage. Get increased capacity, a high-quality Pure Sine Wave output, and extended runtime with each use and tackle your power needs in full confidence.
Driven By Purpose
Over the past decade, we have transformed the alternative energy market by launching a series of high-quality, safe & durable portable generators at affordable prices that were inconceivable when our journey started.
Safe & Eco-friendly Power
All Gentrax products are RCM Australian Standards, United States EPA, and GS (Europe) approved, and Euro 5 certified, making them safe for you and the environment.
12 Years of People-focused Innovation
Products come and go. Technologies evolve. But Gentrax continues to adhere to one core principle: Creating meaningful innovation that improves people’s lives. Be it rain-tested generators, after-warranty replacement, lightweight & compact designs or incredibly affordable prices, Gentrax is and will always be about people.
Proudly Australian
Gentrax is Australian-owned and operated. All Gentrax products are built and tested for Australia’s harsh conditions and shipped from our warehouse in NSW, Australia.
Reliable Power Output
Gentrax provides accessible & reliable power whether for outdoor or backup purposes. This is why all our inverter generators produce a Pure Sine Wave output which is suitable for running sensitive devices. Coupled with a powerful, 4-stroke engine, you'll get nothing less than excellent performance with every use.
90-Day Money Back Guarantee
All Gentrax purchases, including the change-of-mind returns, are eligible for our 90-Day Money Back Guarantee. We only ask that you pay the return cost back to us.
View the Gentrax Range
Support
Whether you need help picking the right product, setting it up, storing or servicing it, we have the resources that could help. Still can't find the information you were looking for? Reach out to our expert team via call or email.
